Bluetooth Speaker Camera

Fitting a new type of everyday device into a room setting in order to obtain covert video and audio surveillance is an ongoing challenge. The Bluetooth Speaker Camera system certainly fulfils the criteria because it is an unobtrusive item that can fit easily in a modern room setting, with the bonus that it will function perfectly as you would expect a standard bluetooth speaker should. A perfect spy camera for the home or office.

WiFi and IP Capability Built-in

Want to watch what is happening live? This unit has both WiFi and IP capability so by using an app on your Smartphone or tablet you can watch streamed video, with audio from the other side of the world if you wish (requires local router link-up). Alternatively you can remote control, stream video and setup the camera system without need for a router from a distance of up to 50 metres. You can download recorded video, set the time to match that on your smartphone or tablet, start/stop recording, format the SD card and even hide the SSID so nobody else can detect your covert camera unit. The video recording memory storage is a micro SD card system that has a maximum capacity of 32GB (a 16GB card is included as standard).

Automatic Motion Detection Recording

Although it is good to be able to view ‘live’ footage, it is not always possible to watch as it happens, so probably one of the most important features of a spy camera system must be the ability to record video footage in response to motion in front of the camera lens automatically. The iBluetooth Speaker Camera uses ‘through the lens’ monitoring technology to achieve this aim and also records watermarked time and date on the video surveillance footage, thereby making this product perfect for gathering a catalogue of video footage suitable for evidential purposes (time/date can be switched off).

Battery or Mains Power – Low Light Capability

The bluetooth speaker has an internal battery that is capable of powering the camera system for up to three hours (with speaker not in use). Alternatively, it can be connected to a mains using the included mains power supply for longer deployments. Many camera systems struggle in subdued lighting conditions, but the 0.1 Lux 78º wide angle camera used in this device can work exceptionally well in low light conditions, albeit not in complete darkness, but there are not many circumstances where this would be absolutely necessary.

Discreet Bluetooth Speaker Camera operation

The design of this Bluetooth Speaker is fairly generic, so it physically should not grab any real attention. The operation of the device is totally discrete in that once setup, there are no flashing lights, sounds or other alerts that would give rise to suspicion in any way that the speaker is anything other than what it appears to be. And the speaker capability is certainly not sub-standard for the size of the unit, so it can be used as a speaker during periods when it is not being used for video capture, thereby completing the disguise.

Small and Powerful

This device is versatile inso many way. It morphs into both home and office environments, it can be used as a normal bluetooth speaker, but the inbuilt self-contained DVR system is capable capturing 1080p video evidence for later watching. Alternatively, used in the capacity of a live video monitoring, it can be remotely monitored on iPhones and Android Smartphones and tablets. Such an array powerful features certainly ensure that the Bluetooth Speaker Camera is worth serious consideration.

Whereabouts is the spy camera located?

If you consider placing the bluetooth speaker on a desk or a table then the camera is in a natural position to overlook a room through a grille in a vertical face.

Does the unit actually work as a bluetooth speaker. Can it broadcast music/sounds into the room?

Yes,  the system is able to provide really quite a decent remote speaker controlled from your Apple or Android device.

Does the camera system have any giveaway signs when motion activated recordings are started and stopped?

The Bluetooth Speaker Camera gives no audible or LED light notifications whatsoever, so there is nothing that will alert unwanted attention.

How do I know whether the camera is recording the right part of the room?

The camera is a wide angled camera model which should provide a decent area of coverage, however to check it then you can view live what the camera is seeing through your smartphone app.

Where would I place such a device?

This really is down to your own personal choice. Bluetooth speakers are commonly found on desktops in the office or at home in the kitchen or maybe in the bedroom in some circumstances.

Does the unit also record decent quality audio?

Yes, the device has an in-built microphone that will easily capture and record clear audio onto the video footage up to a 7 metres radius.

You will need to consider the following to use this equipment:

• You will need use of a computer with speakers attached is required if wishing to playback recordings with the audio. or you can playback through your iOS or Android device.
• If playing back files from the SD card on a computer, you will need a media player on the computer for playback of video / audio files. It maybe worthwhile downloading a free media player. We use VLC Media Player at Spy Equipment UK
• To take full advantage remote live video surveillance, you will need an Android Smartphone, iPhone, Android Tablet or iPad that has an Internet connection.
• Some knowledge of smartphone use and selecting WiFi networks on mobile devices would be useful

• Can play music via bluetooth connected Smartphone
• Live camera view (WiFi P2P) and remote live view (IP) from Smartphone
• Automatically record video footage in response to motion detection
• Set to capture straight uninterrupted video footage
• Set for overwrite of recordings when SD card is full
• Video recordings stored on integrated micro SD Card
• Stream back recorded footage to your Smartphone for playback
• Obtain still image capture via phone app.
• Remotely format inserted SD card

• Built-in image sensor: 1/2.9” progressive CMOS sensor
• Sensor Resolution: 2000 x 1121
• Sensor sensitivity: 0.1 Lux @ F 2.0
• Lens / Focal Length: F 2.0, 3.64 mm
• Field of vision: 78 degrees
• Algorithm: H.264, JPEG
• File formal: MOV, JPG
• Video recording mode: Auto/Manual/Motion Detection
• Recording capability: 1920 x1080, 1280 x720, 848 x 480
• Frame rate: Up to 30 fps
• Photo capability: 2M (1600 x 1200)
• WiFi: Built-in WI-FI module (full IP)
• Memory type: Micro SD Card – Support SDHC 32 GB (max.128 GB if formatted)
• Data interface: Card Reader
• Date / Time: Referenced on actual footage
• Power input: DC 5V
• Power consumption: 480 mA – 530 mA (WiFi ON), BT+ (20 – 380 mA)
• Battery input: DC 3.7V / 1400 mA polymer battery (XK504355)
• Charge time: 180 min (560 mA)
• Battery life: 150 min (1080p) BT off, 165min (720p)BT off, 180 min (WVGA) BT off
• Recording time: 500 min @ 1920 x 1080 resolution (16 GB SD card)
• Dimensions: 86 x 86 x 54 mm
• Weight: 345 grams

• Bluetooth Speaker DVR
• USB connection cable
• 16 GB Micro SD card
• User manuals
